BL High Bays Comfort BL Shine LED luminaires / BL High Bays
Article no.: 740017
BL HB Comfort+ surface/pendant luminaire 487mm 32000lm 200W 110D 840 DALI available
Top Features
-
IK10Impact strength
-
IP65Degree of protection (IP)
-
32000Rated luminous flux according to IEC 62722-2-1
-
yesBall impact resistant
- Quick and easy installation and commissioning thanks to pre-installed 3m connection cable and two-point suspension
- Highest stability thanks to protection class IP65 and Impact resistance IK10 , Protection class I
- ball impact resistant according to DIN 18032-3
High bay luminaire made of aluminium, incl. DALI converter and wire suspension, 32000lm, 200W, 4000K, CRI80, 110°, IP65, IK10, UGR
BL High Bays Comfort
Article 740017
LED High Bay with LED power supply - yes - mounted on housing. Highly efficient lens optics. Cooling housing Aluminium , excellent thermal management, suitable for ambient temperatures of -40...+50 , protection type IP65 , shock resistance IK10 , protection class I, ball-proof - yes - according to DIN 18032-3, service life of 50000 , luminous flux 32000 , connected load 200 , color rendering >80 , color temperature 4000 , beam angle 110 , glare limit <21 ; Dimensions (W x H x L in mm): 362 x 120 x 487
| Mechanical data | |
|---|---|
| Material housing | Aluminium |
| Colour housing | Aluminium |
| Width | 362 |
| Length | 487 |
| Height/depth | 120 |
| Mounting method | Anbau / Pendel |
| Type of control gear | LED - Betriebsgerät stromgesteuert |
| Ball impact resistant | yes |
| Lamp type | LED nicht austauschbar |
| Type of fastening | Seilabhängung / Montagebügel |
| Impact strength | IK10 |
| Degree of protection (IP) | IP65 |
| Control gear included | yes |
| Suspension included in delivery | yes |
| Unified Glare Ratio (UGR) | <21 |
| Electrical data | |
|---|---|
| Protection class | I |
| Voltage type | AC |
| Nominal voltage | 110 - 277 |
| Operating frequency | 50 - 60 |
| Type of dimming | DALI |
| Overall efficiency | 160 |
| Max. system power | 200 |
| Power factor | 0.95 |
| Dimming DALI | yes |
| Light technical data | |
|---|---|
| Beam angle | 110 |
| Colour rendering index CRI | >80 |
| Light exit | direkt |
| Light distribution | symmetrical |
| Rated luminous flux according to IEC 62722-2-1 | 32000 |
| Colour temperature | 4000 |
| Colour of light | White |
| Colour consistency (McAdam ellipse) | SDCM6 |
| Temperature technical data | |
|---|---|
| Impact strength | IK10 |
| Ambient temperature during operating | - 40... + 50 |
| Rated life time L80/B10 at 25 °C | 50000 |
| Packaging information | |
|---|---|
| State of origin | CN |
| Customs tariff number | 94054099 |
| Net width | 362 mm |
| Net height | 120 mm |
| Net length | 487 mm |
