BL Panel Comfort+ EOL LED-Leuchten EOL / BL Panels EOL
BL Panel Comfort + 597mm 3800lm 33W 90D 930 white IP44 900mA available
Top Features
-
WhiteColour housing
-
Surface / Installation / SuspensionMounting method
-
WhiteColour of light
-
<19Unified Glare Ratio (UGR)
- LED panel light with microprismatic layer for modular ceilings with concealed or visible support system
- Best light quality with precise glare control and homogeneous light distribution over the entire light emission surface
- Glare limitation (UGR) <19
LED panel, 3,800 lumens, 33W, 90° direct beam, CRI >90, 3,000 Kelvin, IP44, protection class III, dimmable, UGR
BL Panel Comfort+ EOL
Article 710035
LED panel for installation as Surface / Installation / Suspension - made of high-quality, White coated frames made of sonstige . Microprismatic layer for modular ceilings with concealed or visible support system. Very flat and compact design with a total height of 8 . Best light quality with precise glare control 19 and homogeneous light distribution across the entire light emission surface, service life of 50000 , luminous flux 3800 ; Current max. , color rendering >90 ; light color White , color temperature 3000 ; beam angle 90 , mounting set for Surface / Installation / Suspension must be ordered separately.
Dimensions (L x W x H): 597 x 597 x 8
| Mechanical data | |
|---|---|
| Material housing | sonstige |
| Colour housing | White |
| Width | 597 |
| Length | 597 |
| Height/depth | 8 |
| Mounting method | Surface / Installation / Suspension |
| Lamp type | LED nicht austauschbar |
| Material of the cover | Plastic opal |
| Degree of protection (IP) | IP44 |
| With lamp | yes |
| Control gear included | nein |
| Unified Glare Ratio (UGR) | <19 |
| Electrical data | |
|---|---|
| Protection class | III |
| Voltage type | DC |
| Nominal voltage | 35 - 41 |
| Overall efficiency | 115 |
| Max. system power | 33 |
| Dimming depending on control gear | yes |
| Light technical data | |
|---|---|
| Beam angle | 90 |
| Colour rendering index CRI | >90 |
| Light exit | direkt |
| Light distribution | symmetrical |
| Rated luminous flux according to IEC 62722-2-1 | 3800 |
| Colour temperature | 3000 |
| Colour of light | White |
| Energy efficiency class of teh built-in lamp | F |
| Colour consistency (McAdam ellipse) | SDCM4 |
| Temperature technical data | |
|---|---|
| Ambient temperature during operating | - 20 ... + 40 |
| Rated life time L80/B10 at 25 °C | 50000 |
| Packaging information | |
|---|---|
| State of origin | CN |
| Customs tariff number | 94054239 |
| Net weight | 2700 g |
| Gross weight | 3200 g |
| Gross width | 608 mm |
| Gross height | 24 mm |
| Gross length | 621 mm |
| Net width | 597 mm |
| Net height | 8 mm |
| Net length | 597 mm |
