BILTON AIR SIDE 450 2019 LED modules / BILTON AIR / BILTON AIR SIDE
BLAIRS0450024DC14667840000W05 not available
Top Features
-
24Lamp voltage
-
5000Max. length
-
>80Colour rendering index CRI
-
450Luminous flux per meter
- Homogeneously illuminated light line with no visible light points
- IP67 protection in highly flexible silicone jacket
- Unlimited freedom of design (flexibly deformable and separable)
BILTONAIR SIDE 450 LED strip 24VDC 14,6W/m IP67 CRI>80 4000K WHITE 5m
LED module BILTON AIR SIDE 450 2019
Article 101318
Linear LED light strip on a flexible circuit board. Installation using appropriate mounting accessories in conjunction with Plug-&-Play connection system. Dimmable using BILTON LED dimmer.
Suitable for ambient temperatures from -20 ... +45 at a service life of 50000 .
The BILTON AIR SIDE 450 2019 LED-strip has a luminous flux of 450 at 14.6 , resulting in an efficiency of 31 . At a nominal voltage of 24 DC on the connection, a maximum module length of 5000 can be achieved. In terms of lighting, the module has a colour temperature of 4000 and a beam angle of 120 . All this with a colour rendering index of >80 and a Binning selection based on SDCM3 (MacAdams). The light strip can be separated every 50 , resulting in a LED distance of 7.14 . Degree of protection IP67
Smallest possible bending radius 200
Dimension (L x W x H): 5010 x 13.2 x 16
| Packaging information | |
|---|---|
| State of origin | AT |
| Customs tariff number | 94054039 |
| Net weight | 1130 g |
| Gross weight | 1130 g |
| Gross width | 330 mm |
| Gross height | 27 mm |
| Gross length | 330 mm |
| Net width | 13.2 mm |
| Net height | 16 mm |
| Net length | 5010 mm |
* Information about the electrical and lighting technology measurements: Performance data measured after 1 min. at 25 °C ambient temperature and a light colour of 4,000 K (or RGB). These values can have a tolerance value of -/+ 15%. Module length at 24 V input voltage at the module and luminous flux drop 10% over the specified length.
