BL Casambi Dimmer 2PH BL Shine Lightmanagement / BL Casambi / Casambi actuators and modules
Article no.: 171943
BL Casambi dimmer 2CH PWM available
Dimmer, DALI/0-10V, white plastic, Casambi, mesh network, IP20
BILTON LEDON Technology BL Casambi Dimmer 2PH
Article 171943
The controller BL Casambi Dimmer 2PH is operated with Casambi . The controller and has an output voltage of 100 - 240 .
Dimension (L x W x H): 76 x 26 x 23
| Mechanical data | |
|---|---|
| Material | Kunststoff |
| Width of device | 26 |
| Height of device | 23 |
| Depth of device | 76 |
| Mounting method | sonstige |
| Colour | White |
| Control signal | Casambi |
| Type of fastening | sonstige |
| Core cross section | 0,5 - 1,5 |
| Suitable for degree of protection (IP) | IP20 |
| App controll via Bluetooth | yes |
| Electrical data | |
|---|---|
| Voltage type | AC |
| Number of channels | 6 |
| Frequency | 50 / 60 |
| Control signal | Casambi |
| Nominal voltage | 100 - 240 |
| Standby power consumption (solstandby) | 0.5 |
| Connection | |
|---|---|
| Connection type | Steckklemme |
| Number of channels | 6 |
| Core cross section | 0,5 - 1,5 |
| Temperature technical data | |
|---|---|
| Ambient temperature during operating | - 20... + 45 |
