BL Casambi Dimmer Phases BL Shine Lightmanagement / BL Casambi / Casambi actuators and modules
Article no.: 171942
BL Casambi Dimmer Phase cut available
Dimmer, phase section, white plastic, Casambi, mesh network, IP20
BILTON LEDON Technology BL Casambi Dimmer Phases
Article 171942
The controller BL Casambi Dimmer Phases has a Casambi control signal. Furthermore, the controller operates with a nominal voltage of 85 - 240 and has a IP20 protection rating.
Dimensions (L x W x H): 14 x 40.4 x 36.3
| Mechanical data | |
|---|---|
| Material | Kunststoff |
| Width of device | 40.4 |
| Height of device | 36.3 |
| Depth of device | 14 |
| Colour | White |
| Control signal | Casambi |
| Type of fastening | sonstige |
| Core cross section | 0,5 - 1,5 |
| Suitable for degree of protection (IP) | IP20 |
| App controll via Bluetooth | yes |
| Electrical data | |
|---|---|
| Voltage type | AC |
| Number of channels | 4 |
| Frequency | 50 / 60 |
| Control signal | Casambi |
| Nominal power | 100 |
| Nominal voltage | 85 - 240 |
| Standby power consumption (solstandby) | 0.3 |
| Connection | |
|---|---|
| Connection type | Steckklemme |
| Number of channels | 4 |
| Core cross section | 0,5 - 1,5 |
| Temperature technical data | |
|---|---|
| Ambient temperature during operating | - 20 ... + 45 |
