BL COR Skyline BL Shine LED-Strip / BL Select / BL COR Skyline
BL COR Skyline LED light system 1320lm/m 24VDC 13.5W/m IP20 930 6m black available
Top Features
-
6000Length
-
BlackColour housing
-
LED austauschbarLamp type
-
direct / indirectLight exit
- The flexible rotation axis offers a wide range of angles
- Innovative aluminum strip solution with integrated LED strip
- Simple configuration - cut to length, plug in - done
- Replaceable LED strips up to 13.5 Watt
Skyline black LED lighting system with LED strip 1320 lm/m 24VDC 13.5W/m 98lm/W IP20 CRI>90 3000K WHITE Colours and BLT label 6 metres
LED Module BL COR Skyline
Item 171664
Linear LED strip light on steel tape with movable mounting modules and cable for easy assembly and quick installation.
The BL COR Skyline LED strip light has a luminous flux of 1320 with a power of 13.5 , giving an efficiency of 98 . With a nominal voltage of 24 DC at the connection. In terms of lighting, the module has a color temperature of 3000 and a beam angle of 120 . All with a color rendering index of >90 . The light strip can be divided every 50 , resulting in an LED spacing of 8.33 . Protection class IP20 . Dimensions (L x W x H): 6000 x 35 x 130
| Mechanical data | |
|---|---|
| Colour housing | Black |
| Width | 35 |
| Length | 6000 |
| Height/depth | 130 |
| Lamp type | LED austauschbar |
| Suitable for strip light configuration | yes |
| Distance | 8.33 |
| Distance relating to | LED zu LED |
| Degree of protection (IP) | IP20 |
| With lamp | yes |
| Length of particular segments | 50 |
| Control gear included | nein |
| Light distributor | ohne |
| Electrical data | |
|---|---|
| Protection class | III |
| Voltage type | DC |
| Nominal voltage | 24 |
| Overall efficiency | 98 |
| Max. system power | 13.5 |
| Light technical data | |
|---|---|
| Beam angle | 120 |
| Colour rendering index CRI | >90 |
| Light exit | direct / indirect |
| Light distribution | symmetrical |
| Rated luminous flux according to IEC 62722-2-1 | 1320 |
| Colour temperature | 3000 |
| Colour of light | White |
| Packaging information | |
|---|---|
| State of origin | CN |
| Customs tariff number | 94059900 |
| Net weight | 2000 g |
| Gross weight | 2000 g |
| Gross width | 352 mm |
| Gross height | 70 mm |
| Gross length | 346 mm |
| Net width | 35 mm |
| Net height | 130 mm |
| Net length | 6000 mm |
* Information about the electrical and lighting technology measurements: Performance data measured after 1 min. at 25 °C ambient temperature and a light colour of 4,000 K (or RGB). These values can have a tolerance value of -/+ 10% (or -/+ 15 %at ECO / TWO / RGB / AIR ). Module length at 24 V input voltage at the module and luminous flux drop 10% over the specified length.
