Article no.: 170867
BL LED feeder 4-pole 5A IP20 white for coloured LED strip 2m
BL LED feeder 4-pole 5A IP20 white for coloured LED strip 2m
BL LED feeder 4-pole 5A IP20 white for coloured LED strip 2m
BL LED feeder 4-pole 5A IP20 white for coloured LED strip 2m

BL LED feeder 4-pole 5A IP20 white for coloured LED strip 2m available

Datasheet

Top Features

  • 4
    Number of plug-in contacts
  • 12
    mm
    Net width
  • 5.7
    mm
    Net height
  • 2000
    mm
    Net length

4-pole feeder for coloured LED strips, 5A, IP20, white plastic, 2 metres

BILTON LEDON Technology Feeder 4 pole

Artikel 170867

The connector is a4 pole Feeder with Flat ribbon cable . The connector has a IP20 protection class and the assembly takes place . Max. Rated current 5 .

Dimensions (L x W x H): 2000 mm x 12 mm x 5.7 mm

  • picto-Trash
  • picto-Rohs
  • picto-Ce
Share: Facebook Google+ WhatsApp
Mechanical data
Material housing Kunststoff
Colour housing White
Colour White
Material of contact surface Zinn
Connectable conductor cross section fine-strand w/o ferrule 0,34
Degree of protection (IP), mounted IP20
Number of plug-in contacts 4
Electrical data
Rated voltage 25
Rated surge voltage 0.5
With protective conductor nein
Rated current In 5
Connection
Type of connection Printed circuit board to cable
Contact type Buchse
Type of electric connection Crimpanschluss
Connectable cable type Flat ribbon cable
Modular spacing connections 1.8
Number of plug-in contacts 1
Modular spacing contacts 1.8
Connectable conductor cross section fine-strand w/o ferrule 0,34
Material insulation body Thermoplast
Material contact sonstige Kupferlegierungen
Angle contact/conductor connection sonstige
Number of plug-in contacts 4
Temperature technical data
Ambient/storage temperature - 5 ... + 55
Packaging information
State of origin CN
Customs tariff number 85444290
Net weight 32.9 g
Gross weight 32.9 g
Net width 12 mm
Net height 5.7 mm
Net length 2000 mm
