BL Drive DIM DMX BL Shine power supplies / BL power supply dimmable / Drive Dim SXT
BL Dimmer SXT 230VAC 100W for LED strip IP20 DMX ANALOG available
Top Features
-
220 - 240Imput voltage range
-
100Output power range
-
DMX / AnalogControl signal
-
4000Output current range
1-4 channel LED dimmer for constant voltage 24VDC. Maximum total output 100W at 24VDC (max. 4A). Input voltage 230VAC/50Hz. Control signal DMX or analogue (0-10V). PWM frequency 600Hz. Protection class IP20. Protection class III. dimensions LxWxH = 226x53x45mm
LED dimmer BILTON LEDON Technology BL Drive DIM DMX DMX/Analog
Article 101649
The BL Drive DIM DMX series is a 1- to 4 channel LED dimmer for modules in constant current operation. The total load of max. 4000 can be freely distributed to these 4 channels. The controller is operated with DMX/Analog and 220 - 240 and has an output voltage of 24 DC. The power dissipation in stand-by is 0.5 . The dimming frequency of the PWM signal is 600 . Protection degree IP20 and protection class III .
Dimension (L x W x H): 226 x 53 x 45
| Mechanical data | |
|---|---|
| Housing | Kunststoffgehäuse |
| Width | 53 |
| Length | 226 |
| Height | 45 |
| Model | dynamisch |
| Control signal | DMX / Analog |
| With overheating protection | yes |
| Suitable for outdoor use | nein |
| Degree of protection (IP) | IP20 |
| Core cross section | 0,75 - 1,5 |
| Electrical data | |
|---|---|
| Protection class | III |
| Dimming frequency | 600 |
| Voltage type | AC |
| Number of channels | 4 |
| Control signal | DMX / Analog |
| With overheating protection | yes |
| Imput voltage range | 220 - 240 |
| Output voltage range | 24 |
| Output power range | 100 |
| Output current range | 4000 |
| Type of dimming | DMX |
| Overload protection | yes |
| Standby power consumption (solstandby) | 0.5 |
| Suitable for constant current | nein |
| Suitable for constant voltage | yes |
| Suitable for DC-voltage (primary side) | nein |
| Connection | |
|---|---|
| Number of channels | 4 |
| Core cross section | 0,75 - 1,5 |
| Temperature technical data | |
|---|---|
| Ambient/storage temperature | - 20 ... + 50 |
| Operation temperature at Tc | 0 ... + 50 |
| Ambient temperature during operating | - 5 ... + 45 |
| Lifespan at 20 °C | 40000 |
| Packaging information | |
|---|---|
| State of origin | SI |
| Customs tariff number | 85423190 |
| Net weight | 352 g |
| Gross weight | 395 g |
| Gross width | 58 mm |
| Gross height | 50 mm |
| Gross length | 252 mm |
| Net width | 53 mm |
| Net height | 45 mm |
| Net length | 226 mm |
